DAC - Kustom Groove 215H Bi-Radial 90x90 Horn 1-3/8"-18 TPI

DAC - Kustom Groove 215H Bi-Radial 90x90 Horn 1-3/8"-18 TPI - Image 2

DAC – Kustom Groove 215H Bi-Radial 90×90 Horn 1-3/8″-18 TPI

Name: DAC - Kustom Groove 215H Bi-Radial 90x90 Horn 1-3/8"-18 TPI
Brand: DAC
SKU: 215H
Availability: InStock

₹1,240.00

30 in stock

SKU: 215H Categories: Drivers, Horn Tag: Horn Brand: DAC

DAC – Kustom Groove 215H Bi-Radial 90×90 Horn 1-3/8″-18 TPI

Overview:

Originally used in the Kustom Groove 215H bass cabinet, this 90° x 90° bi-radial horn uses a 1-3/8” 18 TPI mount making it compatible with many popular compression drivers. With a controlled dispersion pattern and rugged ABS construction this horn will work well in any high efficiency speaker design.

Features:

Maintains controlled dispersion down to 1,300 Hz
90° x 90° dispersion pattern help to minimize unwanted reflection
Compact size makes it easy to integrate in smaller speakers
1-3/8” 18-TPI mount for use with many popular compression drivers

Product Details:

Brand	DAC
Model	215H
Unit of Measure	Each
Weight	1

Product Specifications:

Construction	ABS
Entry / Throat Diameter	1″
Mounting Type	1-3/8″-18 TPI
Nominal coverage	90°H x 90° V
Cutoff frequency	1,300 Hz
Dimensions	5.9″ H x 5.9″ W x 3.5″ D
Cutout dimensions	4.75″ H x 4.5″ W.
