Dayton Audio PPA800DSP 2 Way Amplifier Module 800W DSP Bluetooth 5.0 TWS
₹62,762.00 Ex GST
2 in stock
Dayton Audio PPA800DSP 2 Way Amplifier Module 800W DSP Bluetooth 5.0 TWS
Overview:
The Dayton Audio PPA800DSP is an amplifier module capable of developing 800W of power, separated into 2 channels: 600W for low frequencies, 200W for high frequencies. The PPA800DSP incorporates a DSP allowing it to be an excellent amplifier for mounting a configurable 2-way active speaker.
Product Specifications:
Product Type | Amplifier Module |
Power | Low frequencies : 600W RMS (4 Ohm 1kHz @ THD+N 1%) High frequencies : 200W RMS (4 Ohm 8 kHz @ THD+N 0.1%) |
Voice coil inductance, Le | 0.12 mH |
Effective piston area, Sd | 82 cm2 |
Voice coil diameter | 30.5 mm |
Voice coil height | 16 mm |
Air gap height | 5 mm |
Linear coil travel (p-p) | 11 mm |
Magnetic flux density | 1.0 T |
Magnet weight | 0.54 kg |
Net weight | Â 1.46 kg |
Free air resonance, Fs | 37 Hz |
Sensitivity (2.83V/1m) | 88.5 dB |
Mechanical Q-factor, Qms | 3.39 |
Electrical Q-factor, Qes | 0.36 |
Total Q-factor, Qts | 0.32 |
Moving mass incl. air,Mms | 10.2 g |
Force factor, Bl | 4.55 Tm |
Equivalent volume, Vas | 17.3 liters |
Compliance, Cms | 1.81 mm/N |
Mechanical loss, Rms | 0.7 kg/s |
Rated power handling* | c |
Product Highlights:
- Make adjustments from the comfort of your favorite listening chair!
- DSP processing functions include PEQs, HPF, LPF, Phase, Sub Tuning, Mains Delay
- Built-in Auto Room EQ function and microphone for room calibration
- Single-knob control panel with high-contrast LCD display and status LEDs
- Fast, intuitive PC-based GUI software enables full access to the DSP functions
- iPhone Wi-Fi remote control app for convenient control via smart device
- Super-efficient Class D output topology ensures tight, high-impact low frequency performance
DAYTON AUDIO PPA800DSP
2 Way Amplifier Module 800W DSP Bluetooth 5.0
The Dayton Audio PPA800DSP is an amplifier module capable of developing 800W of power, separated into 2 channels: 600W for low frequencies, 200W for high frequencies. The PPA800DSP incorporates a DSP allowing it to be an excellent amplifier for mounting a configurable 2-way active speaker. Thanks to its compact size, it can also be a very good choice for modifying passive speakers. Beyond its audio qualities, Dayton Audio’s PPA800DSP offers many features that make it easy to customize your system.
A fully configurable DSP
The real strength of the PPA800DSP is most likely its customizable integrated DSP. For example, Windows software with a clear and ergonomic interface allows you to adjust levels, filters, equalizers and effects. It is therefore possible to customize the reproduction of this amplifier according to each type of speaker and listening, while offering the possibility of saving profiles.
Adjustable filters
The PPA800DSP allows you to adjust the high-pass and low-pass filters on each output (12 to 48dB/Octave). You can create a seamless transition from your woofer to your tweeter, without the need for passive crossover. In addition, you can also create a subsonic filter to protect the bass drivers or control the tweeters by increasing their response in the high frequencies.
Parametric EQ
For equalization, the PPA800DSP includes 6 bands for each output to adapt the response curve to your needs. In addition, the DSP can store 5 equalizer profiles for quick changes in different situations.
Built-in customizable protection
Professional audio playback systems are designed to operate at full capacity for long periods of time. Under these conditions, it is essential for the equipment to have sufficient protection. Thus, the PPA800DSP includes an adjustable limiter to keep the amplifier output under control. Via different parameters, it is therefore possible to effectively preserve your equipment while keeping all its dynamics.
Adjustable delay time
An important but often overlooked point in the sound and sound dispersion of loudspeakers is the alignment of time. The adjustment of the high and low frequency delay (increment in 0.1ms steps) allows you to make sure that the sound from each speaker reaches you at the same time. It is also possible to calibrate this delay between your speakers and your subwoofer, which can be positioned in a different location.
2 way mixer with Bluetooth
The PPA800DSP also offers a 2-channel mixer integrated directly on the module. Each channel can adjust its XLR input level, line or microphone. In addition, the module integrates a Bluetooth receiver, allowing you to broadcast your music from any device equipped with this technology (smartphone, tablet…). The mixer section also includes an XLR line output to transmit the signal to another powered speaker or subwoofer. It is thus possible to choose between sending the mixed signal or only the channel 2 signal. Finally, the mixer section also features 4 status LEDs: Power, Signal, Limiter and Bluetooth.
