Dayton Audio RSS210HF-4 8″ Reference Series HF Subwoofer 4 Ohm
₹16,643.00
3 in stock
Dayton Audio RSS210HF-4 8″ Reference Series HF Subwoofer 4 Ohm
Overview:
The Dayton Audio Reference Series subwoofers take the quality and performance of the much acclaimed RS line into the subwoofer realm. The black anodized cone, rubber surround, and custom basket give this driver a unique, high-end look
Key Features:
- Extensively vented motor eliminates compression and allows quiet excursion
- Lightweight black anodized aluminum cone for rigidity and lower moving mass
- Suitable for sealed or vented enclosures
- Triple shorting ring motor for ultra-low distortion
- 2-layer coil for reduced back EMF
- Highest quality materials throughout for long-lasting performance
Product Details:
Brand | Dayton Audio |
Model | RSS210HF-4 |
Unit of Measure | Each |
Weight | 8.8 |
Product Specification:
Nominal Diameter | 8″ |
Power Handling (RMS) | 280Â Watts |
| Â Â Â Â Â Â Â Â Â Power Handling (MAX) | 560Â Watts |
Sensitivity | 85.6dB 2.83V/1m |
Voice Coil Diameter | 2″ |
Frequency Response | 27 to 1,000Hz |
|   Impedance | 4Ω |
Thiele Small Parameters:
Resonant Frequency (Fs) | 29.6Hz |
DC Resistance (Re) | 3.1Ω |
Voice Coil Inductance (Le) | 0.7mH |
Mechanical Q (Qms) | 3.25 |
Electromagnetic Q (Qes) | 0.69 |
Total Q (Qts) | 0.57 |
Compliance Equivalent Volume (Vas) | 0.84ft³ |
Mechanical Compliance of Suspension (Cms) | 0.37mm/N |
BL Product (BL) | 8.12T·m |
Diaphragm Mass Inc. Airload (Mms) | 78.4g |
Maximum Linear Excursion (Xmax) | 9mm |
Surface Area of Cone (Sd) | 219cm² |
Materials of Construction:
Cone Material | Â Â Â Â Â Â Â Â Â Â Â Â Â Aluminum |
Surround Material | Â Â Â Â Â Â Â Â Â Â Â Â Â Rubber |
| Â Â Voice Coil Wire Material | Â Â Â Â Â Â Â Â Â Â Â Â Â Copper |
| Â Voice Coil Former | Â Â Â Â Â Â Â Â Â Â Â Â Aluminum |
| Basket / Frame Material | Â Â Â Â Â Â Â Â Â Â Â Â Â Steel |
Magnet Material | Â Â Â Â Â Â Â Â Â Â Â Â Â Ferrite |
Mounting Information:
Overall Outside Diameter | Â Â Â Â Â Â Â Â Â Â Â Â Â 8.39″ |
| Baffle Cutout Diameter | Â Â Â Â Â Â Â Â Â Â Â Â Â 7.28″ |
| Depth | Â Â Â Â Â Â Â Â Â Â Â Â Â 4.88″ |
| # Mounting Holes | Â Â Â Â Â Â Â Â Â Â Â Â Â Â 6 |
Â
Dayton Audio RSS210HF-4 Specifications
Dayton Audio RSS210HF-4 Graphs/FRD/ZMA Data File
| Weight | 4200 g |
|---|---|
| Dimensions | 24 × 24 × 17 cm |
