DAC – EAS10P241JD3 4″ Paper Cone Full-Range Speaker 4 Ohm
Overview:
The EAS10P241JD3 4″ Paper Cone Full-Range Speaker utilizes a paper cone and treated paper surround for excellent damping characteristics.
Features:
- Rear-mount design helps hide mounting hardware
- Great replacement in vintage boomboxes and small stereos
- Small mounting flange makes this a good contender for line arrays
Product Details:
Brand | DAC |
Model | EAS10P241JD3 |
Unit of Measure | Each |
Weight | 0.4 |
Product Specifications:
Nominal Diameter | 4″ |
Bolt Circle Diameter | 4.25 |
Power Handling (RMS) | 5 Watts |
Power Handling (MAX) | 10 Watts |
Impedance | 4Ω |
Frequency Response | 125 to 10,000Hz |
Sensitivity | 89.81dB 2.83V/1m |
Voice Coil Diameter | 0.5″ |
Thiele-Small Parameters:
Resonant Frequency (Fs) | 124Hz |
DC Resistance (Re) | 3.587Ω |
Mechanical Q (Qms) | 6.18 |
Electromagnetic Q (Qes) | 1.311 |
Total Q (Qts) | 1.081 |
Compliance Equivalent Volume (Vas) | 0.1503ft³ |
Diaphragm Mass Inc. Airload (Mms) | 1.591g |
Maximum Linear Excursion (Xmax) | 0.625mm |
Surface Area of Cone (Sd) | 54.11cm² |
Materials of Construction:
Cone Material | Paper |
Surround Material | Paper |
Voice Coil Wire Material | CCA |
Voice Coil Former | Paper |
Basket / Frame Material | Steel |
Magnet Material | Ferrite |
Mounting Information:
Overall Outside Diameter | 4″ |
Baffle Cutout Diameter | 3.625″ |
Depth | 1.625″ |
# Mounting Holes | 4 |
| Weight | 800 g |
|---|---|
| Dimensions | 15 × 5 × 7 cm |
