SEAS Prestige 19TFF1 – H0737 3/4″ Textile Dome Tweeter
₹3,686.00
Out of stock
SEAS Prestige 19TFF1 – H0737 3/4″ Textile Dome Tweeter
Highlights
- Smooth, extended frequency response
- Precoated Sonotex fabric diaphragm and suspension allows a fundamental frequency response of 4,000 to 20,000 Hz
- 90 Watts RMS Power Handling
- 88 dB 2.83V/1m Sensitivity
Product details:
19mm High Fidelity dome tweeter with extremely smooth and extended frequency response. Precoated Sonotex fabric diaphragm and suspension allows for very tight production tolerances and high consistency. Injection molded chassis in high grade glass fiber reinforced plastic keeps the moving parts in perfect alignment and provides good coupling to the cabinet. Voice coil windings immersed in magnetic fluid increase short term power handling capacity and reduce the compression at high power levels.
Product Specification:
Tweeter Type | Textile Dome |
Tweeter Series | Prestige Series |
Cone / Dome Diameter | 19 mm | 3/4″ |
Power Handling (RMS) | 90 Watts |
Power Handling (max) | 90 Watts |
Impedance (Z) | 8 Ω |
Sensitivity | 88 dB 2.83V/1m |
Frequency Response | 4,000 to 20,000 Hz |
Resonant Frequency (Fs) | 1,700 Hz |
DC Resistance (Re) | 6.2 ohms |
Voice Coil Inductance (Le) | 0.05 mH |
Overall Outside Diameter | 3.69″ |
Cutout Diameter | 2.62″ |
Depth | 0.83″ |
Product Manuals / Spec Sheets / Downloads: Click Here.
