SEAS Prestige MCA15RCY H1262-08 Coated Paper Midrange 5″/8Ohm
₹11,800.00
10 in stock
SEAS Prestige H1262-08 MCA15RCY Coated Paper Midrange 5″/8Ohm
Overview:
Seas Prestige MCA15RCY is a 15 cm (5’’) cone driver, developed for use as a high quality midrange unit. Classically coated paper cone gives a smooth extended frequency response with a controlled roll off. The large magnet system, together with the light cone give high sensitivity with low distortion and good transient response. Extremely stiff and stable injection moulded metal basket keeps the critical components in perfect alignment. Large windows in the basket both above and below the spider reduce sound reflection, air flow noise and cavity resonance to a minimum.
Highlights:
- Long term power handling (RMS) is 100 Watts
- Large magnet system and the light cone give high sensitivity with low distortion and good transient response
- Reduced sound reflection, air flow noise and cavity resonance
Product Details:
Model | MCA15RCY |
Product Type | Midrange |
Product Series | Prestige Series |
Nominal Diameter | 5″ |
Specifications:
Nominal Impedance | 8 Ohms |
Recommended Frequency Range | 100 – 4000 Hz |
Short Term Power Handling | 300 W |
Long Term Power Handling | 100 W |
Characteristic Sensitivity (2.83V, 1m | 89.5 dB |
Voice Coil Diameter | 26 mm |
Voice Coil Height | 9.4 mm |
Air Gap Height | 6.0 mm |
Linear Coil Travel (p-p) | 3.4 mm |
Maximum Coil Travel (p-p) | 14 mm |
Magnetic Gap Flux Density | 1.25 T |
Magnet Weight | 0.42 kg |
Total Weight | 1.3 kg |
Voice Coil Resistance | 5.8 Ohms |
Voice Coil Inductance | 0.73 mH |
Force Factor | 6.8 N/A |
Free Air Resonance | 51 Hz |
Moving Mass | 7.1 g |
Air Load Mass in IEC Baffle | 0.42 g |
Suspension Compliance | 1.4 mm/N |
Suspension Mechanical Resistance | 1.53 Ns/m |
Effective Piston Area | 80 cm |
VAS | 12 Litres |
QMS | 1.57 |
QES | 1.30 |
QTS | 0.25 |
Frequency Response:
Dimensions:
H1262-08 Data Sheet
