SEAS Prestige H1658-04 MU10RB-SL MidRange 4Ohm/4″
Overview:
Highlights:
- Long term power handling (RMS) is 40 Watts
- New Curv cone, a woven polypropylene with excellent internal damping
- The pole piece is prolonged forwards and equipped with a deep drawn copper cap to ensure excellent linearity in the force factor and coil inductance
Product Details:
Model | MU10RB-SL |
Driver Type | Midrange |
Driver Series | Prestige Series |
Nominal Diameter | 4″ |
Specifications:
Nominal Impedance | 4 Ohms |
Recommended Frequency Range | 100 – 20000 Hz |
Short Term Power Handling | 100 W |
Long Term Power Handling | 40 W |
Characteristic Sensitivity (2.83V, 1m | 84.7 dB |
Voice Coil Diameter | 19 mm |
Voice Coil Height | 8 mm |
Air Gap Height | 4 mm |
Linear Coil Travel (p-p) | 4 mm |
Maximum Coil Travel (p-p) | 7.9 mm |
Magnetic Gap Flux Density | 0.9 T |
Magnet Weight | 0.09 kg |
Total Weight | 0.36 kg |
Voice Coil Resistance | 3.3 Ohms |
Voice Coil Inductance | 0.14 mH |
Force Factor | 2.9 N/A |
Free Air Resonance | 100 Hz |
Moving Mass | 4.51 g |
Air Load Mass in IEC Baffle | 0.14 g |
Suspension Compliance | 0.6 mm/N |
Suspension Mechanical Resistance | 1.8 Ns/m |
Effective Piston Area | 38.5 cm |
VAS | 1 Litres |
QMS | 1.63 |
QES | 1.15 |
QTS | 0.67 |
Frequency Response:

Dimensions:
