DAC – 40T-256A 1-1/2″ Neodymium Paper Cone Tweeter 6 ohm

Name: DAC - 40T-256A 1-1/2" Neodymium Paper Cone Tweeter 6 ohm
Brand: DAC
SKU: 40T-256A
Availability: InStock

₹459.00

32 in stock

SKU: 40T-256A Categories: Drivers, Tweeter Tags: 40T256A, 6Ohm Brand: DAC

DAC – 40T-256A 1-1/2″ Neodymium Paper Cone Tweeter 6 ohm

Overview:

The 40T-256A 1-1/2″ Neodymium Paper Cone Tweeter utilizes an oversize neodymium motor and a very light 0.4 gram paper cone for incredible output capability.

Key Features:

Easy installation into a 1-1/2″ diameter hole
Third “dummy” terminal makes adding a capacitor simple
Paper cone for smooth natural sound

Product Details:

Brand	DAC
Unit of Measure	Each
Weight	0.1

Product Specification:

Bolt Circle Diameter	1.875
Power Handling (RMS)	13 Watts
Power Handling (MAX)	26 Watts
Impedance	6Ω
Frequency Response	2,000 to 20,000Hz
Sensitivity	87dB 2.83V/1m
Voice Coil Diameter	0.5″

Thiele Small Parameters:

Resonant Frequency (Fs)	1484Hz
DC Resistance (Re)	4.665Ω
Mechanical Q (Qms)	2.056
Electromagnetic Q (Qes)	11.59
Total Q (Qts)	1.746
Diaphragm Mass Inc. Airload (Mms)	0.4g
Surface Area of Cone (Sd)	10.75cm²
