Nominal Diameter

160 mm (6 in)

Overall Diameter

186.5/162 mm (7.34/6.37 in)

Bolt Circle Diameter

172 mm (6.77 in)

Baffle Cutout Diameter

147 mm (5.79 in)

Depth

76 mm (2.99 in)

Flange and Gasket Thickness

11 mm (0.43 in)

Net Weight

1.2 kg (2.6 lb)

Fs

65 Hz

Re

5.3 Ohm

Qes

0.28

Qms

5.8

Qts

0.27

Vas

9.3 dm^3 (0.33 ft^3)

Sd

133 cm^2 (20.62 in^2)

Xmax (4)

5.60 mm

Xdamage (5)

11.6 mm

Mms

16.0 g

Bl

11 N/A

Le

0.28 mH

Mmd

14.3 g

Cms

0.37 mm/N

Rms

1.1 kg/s

Eta Zero

0.86 %

EBP

232 Hz

Nominal Impedance

8 Ohm

Minimum Impedance

6.3 Ohm

AES Power Handling (1)

200 W

Maximum Power Handling (2)

400 W

Sensitivity (1W/1m)

93 dB

Frequency Range

60÷6000 Hz

Voice Coil Diameter

44 mm (1.73 in)

Winding Material

Al

Former Material

Glass Fiber

Winding Depth

13.2 mm (0.52 in)

Magnetic Gap Depth

6 mm (0.24 in)

Flux Density

1.5 T

Magnet

Neodymium Ring

Basket Material

Aluminum

Demodulation

Aluminum Ring

Cone Surround (3)

Half Roll

NET Air Volume filled by Loudspeaker

0.37 dm^3 (0.013 ft^3)

Spider Profile

1x variable height waves
