SB Audience Bianco 25CD-P Compression Driver- 1″
₹1,812.00
19 in stock
SB Audience Bianco 25CD-P Compression Driver- 1″
Highlights:
- Exremely light weight PEI diaphragm
- Smooth response with airy detailed highs
- High sensitivity and compact design
Product Specifications:
Nominal Impedance | 8 Ohm |
Minimum Impedance | 5.5Ohm |
AES Power Handling (1) | 20 W |
Maximum Power Handling (2) | 40 W |
Sensitivity (1W/1m) | 109 dB |
Frequency Range | 1000 – 20000 Hz |
Voice Coil Diameter | 25 mm (0.98in) |
Winding Material | Copper clad aluminium |
Former Material | kapton |
Winding Depth | 1.78 mm(0.070 in) |
Magnetic Gap Depth | 2 mm (0.08 in) |
Flux Density | 1.7 T |
Magnet | Ferrite |
Basket Material | – |
Demodulation | – |
Cone Surround | – |
NET Air Volume filled by driver | 0.29 liters |
Spider Profile | Single constant height waves |
Weather Resistant | – |
Dimensions & Weight:
Diameter | 25.4 mm (1.0 in) |
Bolt Circle Diameter | 294 mm (11.57in) |
Baffle cutout Diameter | 276mm (10.86 in) |
Mounting Depth | 122.5 mm (4.82 in) |
Net Weight | 3.6 kg (7.92 lb) |
Shipping Box | 354 X 354 X 182 mm |
Gross Weight | 4.69 Kg (10.33 lb) |
Flange and Gasket Thickness | 9.6 mm (0.37 in) |
NOTES :
Driver mounted on Horn250
(1) 2hours test made with continuous pink noise signal within the range from the recommended crossover frequency to 20KHZ
(2) Maximum power is defined as 3dB greater than nominal power.
(3) Averaged within the frequency range.
(4) Xmax=((winding depth-Magnetic gap depth)/2+(Magnetic gap depth/3)
Bianco 25CD-P Specifications Please Click Here
NOTE: Delivery charges may vary based on Area/Weight of the product
| Weight | 840 g |
|---|---|
| Dimensions | 90 × 90 × 56.3 cm |
